Key Points:
Fine finish
Waterproof
Resistant to agricultural chemicals
Lightweight
Features:
Puncture, abrasion and chemical resistant construction with a high strength HDPE woven core that provides superior dimension stability.
Outstanding UV, ozone and oxidation resistance.
Non-toxic, no PVC or other hazardous materials used in construction of fabric.
Low water vapor permeance.
Key Points:
Fine finish
Waterproof
Resistant to agricultural chemicals
Lightweight
GUJARAT CRAFT INDUSTRIES LIMITED committed towards manufacturing, exporting and supplying a wide variety of excellent quality Tent Tarpaulin
Towards our commitment for protecting nature, environment and natural resources we manufacture Geomembrane and Pond Liners. Geomembrane are a reinforced woven polyolefin liners that offer exceptional hydrostatic resistance for buried and exposed containment applications. For applications where liquid containment is critical, GCILs Geomembrane proprietary engineered fivelayer construction which will provide maximum performance in all climates and environmental conditions. We manufacture liners with UV (UltraViolet) stabilised fabrics.
standerd :- 300micron /500 micron/750 micron
Key Points:
Seamless finish
Easy to use
Very light in weight

Size Reinforced plastic tarpaulin in 4m x 6m sheet or 4m x 60m roll
Material Woven high-density polyethylene (HDPE) black fibers fabric,
fabric laminated on both sides with white low density polyethylene (LDPE) coating, reinforced with 6 bands of 75 mm width woven black HDPE fibers fabric and coated with grey LDPE on the outside. Pre-punched 8mm holes on the 2 side bands at 0.1m +/-10% intervals, positioned in the Centre of the bands (only the reinforcement bands are pre-punched, not the tarpaulin itself.
Weight 190 20g under ISO 3801 (equivalent to min 170 to 210 gsm max.
Tensile strength Min 500N, 15-25% elongation in warp and weft in plain sheet under ISO 1421-1
Reinforcement bands Min 700N as per ISO 1421-1, pulling lengthwise in a pre-punched 8mm hole with a hook of 8 mm wire diameter, at 200mm from the end of the band. UV resistance 80% of original value and not less than 665N.
Tear strength Min 100N under ISO 1421outside of the Reinforcement Bands.
UV resistance After 1500 hours UV under ASTM G53/94 (UVB 313 nm peak) minimum 80% of original value of the actual product and not less than 475N
Welding Only 1 welding lengthwise.

Size Reinforced plastic tarpaulin in 4m x 6m sheet or 4m x 60m roll
Material Woven high-density polyethylene (HDPE) black fibers fabric, fabric laminated on both sides with white low density polyethylene (LDPE) coating, reinforced with 6 bands of 75 mm width woven black HDPE fibers fabric and coated with grey LDPE on the outside. Pre-punched 8mm holes on the 2 side bands at 0.1m +/-10% intervals, positioned in the Centre of the bands (only the reinforcement bands are pre-punched, not the tarpaulin itself).
Weight 190 20g under ISO 3801 (equivalent to min 170 to 210 gsm max)
Tensile strength Min 500N, 15-25% elongation in warp and weft in plain sheet under ISO 1421-1
Reinforcement bands Min 700N as per ISO 1421-1, pulling lengthwise in a pre-punched 8mm hole with a hook of 8 mm wire diameter, at 200mm from the end of the band. UV resistance 80% of original value and not less than 665N.
Tear strength Min 100N under ISO 1421outside of the Reinforcement Bands.
UV resistance After 1500 hours UV under ASTM G53/94 (UVB 313 nm peak) minimum 80% of original value of the actual product and not less than 475N
Welding Only 1 welding lengthwise.
